Limitations
There are size and resolution limitations for the Mirror, Deflection and both
Extrusion Wraps: The maximum size in both directions covered by the actions is
a bit less than 6 meters = 20 feet. The stretcher bar thickness can be 2 inches
maximum, there is a 3mm = 1/8 inch tolerance per side added automatically.
At the stretcher frame size settings, an action stop, the resulting resolution has to
be above 20 PPI. You can always upsample in that first choice of the action to
get above 20 PPI so it is not really a limitation. However it is not recommended
to upsample when the 20 PPI or more is already available. The action will take
more time than necessary if you select a high PPI number there right away.
Canvas print quality usually requires less than 300 PPI input to the driver and
optimal quality will already be available at 150-200 PPI input, the quality of the
wrap isn't getting better with higher numbers and overall time in processing and
printing increases. So keeping the resolution at 200 PPI or lower may be wiser
but given enough computing power and scratch disc capacity it could be used
with higher PPI numbers. Large frames and high PPI numbers will take a lot of
time to process depending on the system the software runs on.
Some comments
Please, always check the edges on the monitor at 100% to see whether it is done
correctly. By making the actions universal for sizes up to almost 6 meter and for
high and low resolutions there can be artefacts that are only visible in the print
or with higher magnifications on the monitor. As a result of copying the image
edges there is the more pronounced double image edge with all the flaws you
wouldn't see on the normal image. Light fall-off on the edges, the scan that
should have been cropped a bit more, it all becomes more pronounced when the
edge is doubled with mirroring etc. Some samples on the pages will show that
the top edge of the image and the copied wrap at that side is too light at the
frames edge etc. It isn't retouched here to show what can happen.
With the Plain Wrap there's a chance that you will select a frame side color that
is beyond the gamut of the image itself, in the conversion to the printer profile
this darker or more saturated color influences the image color depending on the
rendering chosen. To avoid that issue you could select a color in the image itself
with the Eyedropper tool or do the conversion to the printer profile (P2P) on the
image before the actions and then print with color management off.
Copyright to all actions, action methods, texts, on this site and to certain
photographs used to illustrate them are held by the developer Ernst Dinkla. The
site itself and some photographs are copyright 2006 by Ernst Dinkla, Dinkla
Grafische Techniek, The Netherlands. All right reserved. The actions have been
tested on all Photoshop versions up to CS 5.5 and their respective platform
versions. No issues were reported. The actions were not tested on other
applications that may load Photoshop actions.
